Micron MTFDLAL30T7THL-1BK1DFCYYR – 6550 ION 30.72TB U.2 NVMe Enterprise SSD
Roll over image to zoom in
53,063.73 AED54,599.90 AED (-3%)
Key Features
• 30.72TB ultra-high capacity enterprise SSD
• PCIe Gen5 x4 NVMe interface for maximum throughput
• U.2 2.5-inch form factor for data center compatibility
• Up to 14GB/s read performance for AI workloads
• Designed for hyperscale and cloud storage environments
Micron MTFDLAL30T7THL-1BK1DFCYYR – 6550 ION 30.72TB U.2 NVMe Enterprise SSD
Overview
Micron MTFDLAL30T7THL-1BK1DFCYYR is a high-capacity enterprise NVMe solid state drive from the Micron 6550 ION series, designed for hyperscale data centers and AI-driven storage infrastructures. It is used in environments requiring extremely high density storage with predictable performance and enterprise reliability.
The drive provides 30.72TB capacity and operates on a PCIe 5.0 x4 NVMe interface in a U.2 2.5-inch (15mm) form factor. It is optimized for large-scale data workloads such as AI data lakes, cloud storage, and high-throughput analytics systems. Verified specifications show sequential read speeds up to ~14,000 MB/s and write speeds up to ~7,000 MB/s.
It is deployed in hyperscale servers, enterprise storage arrays, and cloud infrastructure where high capacity per rack unit is critical. The drive uses 3D TLC NAND and is engineered for low write workload intensity environments (around 0.25 DWPD), focusing on read-heavy enterprise usage patterns.
Integration is done via U.2 NVMe backplanes or compatible EDSFF/U.2 enterprise storage systems, making it suitable for modern rack-scale architectures and disaggregated storage designs.
It is not suitable for consumer PCs, gaming systems, or traditional SATA-based infrastructure due to its enterprise form factor, power profile, and workload specialization.
Typical Deployment Scenarios
• Hyperscale cloud storage infrastructure
• AI/ML data lake and training dataset storage
• Enterprise analytics and big data platforms
• High-density rack server storage arrays
• Large-scale virtualization and container storage layers
Specifications
| Specification | Value |
|---|---|
| Brand | Micron |
| Part Number | MTFDLAL30T7THL-1BK1DFCYYR |
| Product Type | Enterprise NVMe SSD |
| Series | 6550 ION |
| Capacity | 30.72TB |
| Form Factor | U.2 2.5-inch (15mm) |
| Interface | PCIe Gen5 x4 |
| Protocol | NVMe 2.0 class |
| NAND Type | 3D TLC NAND |
| Sequential Read | Up to ~14,000 MB/s |
| Sequential Write | Up to ~7,000 MB/s |
| Random Read | Up to ~2,000,000 IOPS |
| Random Write | Up to ~70,000 IOPS |
| Endurance | ~0.25 DWPD |
| MTBF | ~2.5 million hours |
| Operating Temperature | 0°C to 70°C |
| Power Consumption | Enterprise class (variable load dependent) |
| Weight | ~150g (approx.) |
Compatibility / Ecosystem
Micron MTFDLAL30T7THL-1BK1DFCYYR integrates into enterprise U.2 NVMe ecosystems including hyperscale servers, OEM storage arrays, and cloud infrastructure platforms. It supports modern data center architectures using PCIe Gen5 backplanes and is typically deployed in rack-scale storage systems with redundant power and cooling.
Additional information
| Weight | 0.178 kg |
|---|---|
| Dimensions | 10.05 × 7.01 × 1.50 cm |
| Brand | Micron |
