Micron MTFDDAK960TGB-1BC16ABYYR – 5400 MAX 960GB 2.5″ SATA Enterprise SSD
3,432.70 AED3,465.00 AED (-1%)
Key Features
• 960GB SATA SSD with mixed-use enterprise endurance
• Up to ~5 DWPD for write-intensive workloads
• 176-layer TLC NAND for data center reliability
• AES-256 and TCG Enterprise encryption support
• 2.5-inch hot-swap compatible server form factor
Micron MTFDDAK960TGB-1BC16ABYYR 5400 MAX 960GB 2.5″ SATA Enterprise SSD
Overview
Micron MTFDDAK960TGB-1BC16ABYYR is a data center-class solid state drive from the 5400 MAX series, designed for enterprise environments requiring high endurance and consistent performance in SATA-based storage tiers. It is deployed in server infrastructure, virtualization clusters, and enterprise storage arrays where reliability and predictable latency are critical.
The drive provides 960GB capacity and operates over a SATA III 6Gbps interface, delivering sequential performance up to ~540 MB/s read and ~520 MB/s write. It uses 176-layer 3D TLC NAND and is classified under the MAX category, supporting up to ~5 DWPD endurance, making it suitable for mixed-use workloads with sustained write activity.
It is commonly deployed in rack servers, hyperconverged infrastructure, and enterprise RAID environments where SATA SSDs are used alongside SAS or NVMe drives for tiered storage strategies. The 2.5-inch 7mm form factor allows integration into standard hot-swap bays.
Integration includes support for enterprise security standards such as TCG Enterprise encryption and AES-256 hardware-based data protection. It is validated for continuous 24/7 operation in data center environments with high MTBF reliability.
This drive is not intended for ultra-low latency NVMe workloads or hyperscale AI storage systems, as it is optimized for SATA-based infrastructure and mixed-use enterprise performance rather than maximum throughput.
Typical Deployment Scenarios
• Enterprise server boot and application storage
• Virtualization clusters with mixed workloads
• RAID-based storage arrays in data centers
• Database and transactional application environments
• SATA SSD tier in hybrid storage architectures
Specifications
| Specification | Value |
|---|---|
| Brand | Micron |
| Part Number | MTFDDAK960TGB-1BC16ABYYR |
| Product Type | Enterprise Solid State Drive |
| Capacity | 960 GB |
| Form Factor | 2.5-inch (7mm) |
| Interface | SATA III 6Gbps |
| NAND Type | 3D TLC (176-layer) |
| Endurance | Up to ~5 DWPD (MAX series) |
| Max Sequential Read | Up to ~540 MB/s |
| Max Sequential Write | Up to ~520 MB/s |
| Random Read IOPS | Up to ~95,000 |
| Random Write IOPS | Up to ~65,000 |
| Encryption | AES-256 / TCG Enterprise |
| MTBF | ~3 million hours |
| Operating Temperature | 0°C to 70°C |
| Form Factor (H × W × D in inches) | 0.28 × 2.75 × 3.95 |
| Weight (lbs) | ~0.15 |
Compatibility / Ecosystem
Micron MTFDDAK960TGB-1BC16ABYYR integrates into enterprise SATA ecosystems including Dell, HPE, and Lenovo server platforms. It is compatible with RAID controllers, hot-swap backplanes, and storage arrays using 2.5-inch SATA bays. It is commonly used as part of tiered storage architectures alongside SAS and NVMe SSDs.
Additional information
| Weight | 0.07 kg |
|---|---|
| Dimensions | 10.045 × 6.985 × 0.7 cm |
| Brand | Micron |
