HPE 876144-001 – 10GbE SFP+ SR Optical Transceiver
Roll over image to zoom in
Key Features
- 10GbE SR multimode fiber connectivity
- 850nm VCSEL optical transmission
- LC duplex fiber interface support
- Hot-swappable SFP+ module design
Please fill the form to get price quote.
HPE 876144-001 – 10GbE SFP+ SR Optical Transceiver
Overview
HPE 876144-001 is a 10 Gigabit Ethernet SFP+ short reach optical transceiver designed for multimode fiber connectivity in enterprise data center networks. It enables reliable 10GbE optical links between switches, servers, and storage systems.
It operates using 850nm VCSEL technology over LC duplex multimode fiber, supporting short-distance high-speed data transmission.
It is commonly used in rack-based networking environments where high bandwidth and low latency connections are required.
The module supports hot-pluggable operation, allowing installation or replacement without disrupting active network traffic.
It is typically deployed in HPE enterprise networking infrastructure supporting SFP+ SR optical links.
Typical Deployment Scenarios
Used in enterprise data centers for 10GbE server-to-switch uplinks over multimode fiber. Common in rack switching architectures and high-density network deployments. Also used in virtualization clusters and storage networks requiring short-reach optical connectivity.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | HPE |
| Part Number | 876144-001 |
| Product Type | SFP+ 10GbE SR Transceiver |
| Form Factor | SFP+ |
| Data Rate | 10.3 Gbps |
| Wavelength | 850 nm |
| Fiber Type | Multimode fiber (MMF) |
| Connector Type | LC Duplex |
| Maximum Reach | Up to 300 m (OM3), 400 m (OM4) |
| Optical Technology | VCSEL |
| Digital Diagnostics | Supported |
| Hot Pluggable | Yes |
| Power Consumption | < 1 W |
| Operating Temperature | 0°C to 70°C |
| Media Support | OM3 / OM4 fiber cabling |
Compatibility / Ecosystem
Compatible with HPE 10GbE SFP+ supported switches and server networking platforms. Works with LC duplex multimode fiber cabling (OM3/OM4). Designed for integration into enterprise data center optical networking environments.
Additional information
| Weight | 0.02 kg |
|---|---|
| Dimensions | 22.86 × 15.24 × 0.16 cm |
