Cisco PWR-IE170W-PC-DC | 170 W DIN-rail DC-to-DC Power Supply

Cisco PWR-IE170W-PC-DC – Industrial DIN-rail Power Supply / 170 W output

Overview :

The Cisco PWR-IE170W-PC-DC is a 170 W DC-to-DC industrial power supply intended for use in rugged networking environments by network engineers and integrators. It accepts a nominal input range of 12 V to 54 V DC (supported range 10.8–60 VDC) and provides a regulated 54 V DC output suitable for powering industrial Ethernet switches and PoE deployments. With an efficiency typical of 88 % and a holdup time of 9 ms at full load, the unit is designed to maintain stability under transient conditions. The module is DIN-rail mountable, carries an IP20 rating, and supports deployment in Class 1, Div 2 / Zone 2 hazardous locations. It is therefore suited for settings such as manufacturing plants, outdoor cabinets, and transportation networks where robust, cabinet-friendly power conversion is required.

Key Features :

• 170 W DC-to-DC output rated at 54 V DC

• Wide low-voltage input: 10.8–60 V DC nominal 12–54 V DC

• DIN-rail form factor, IP20 rated for industrial cabinets

• Holdup time of ~9 ms at 100 % load ensures transient stability

• Certified for Class 1 Div 2 / Zone 2 hazardous-location installations

Specifications :
