Cisco IE-1000-4P2S-LM-N Industrial Ethernet 1000 Series – 6-Port Managed Industrial Switch with 4 PoE+ and 2 SFP Uplink Ports
Roll over image to zoom in
3,133.20 AED3,201.45 AED (-2%)
Cisco
IE-1000-4P2S-LM-N Industrial Ethernet 1000 Series – 6-Port Managed Industrial Switch with 4 PoE+ and 2 SFP Uplink Ports
The Cisco IE-1000-4P2S-LM-N is a robust and compact managed Ethernet switch designed specifically for industrial environments where reliability, simplicity, and ruggedness are paramount. Engineered for operational continuity in manufacturing plants, outdoor enclosures, transportation networks, and building automation, this 6-port switch features four 10/100/1000Base-T PoE+ ports and two 1GbE SFP uplinks for fiber connectivity. Its fanless DIN-rail-mountable metal enclosure is optimized for space-constrained environments and offers extended temperature tolerance from –40°C to +75°C. The device delivers enterprise-grade Layer 2 features such as VLAN segmentation, Quality of Service (QoS), Spanning Tree Protocol (STP), and DHCP snooping—all through an intuitive GUI or optional CLI/SNMP for industrial deployments with or without IT support.
Features :
The Cisco Industrial Ethernet 1000 Series is crafted for harsh-edge deployments where standard switches cannot operate effectively. The IE-1000-4P2S-LM-N provides rugged network connectivity for critical infrastructure that requires high availability, low latency, and energy efficiency. Equipped with four PoE+ ports delivering up to 30W per port (total PoE budget of 120W), it supports a variety of powered devices such as IP cameras, access control units, environmental sensors, and wireless access points. Its two SFP ports allow for flexible fiber uplinks, ideal for long-distance or EMI-sensitive deployments.
Advanced Options :
With built-in Layer 2 features such as VLANs, IGMP snooping, and port-based QoS, the switch enables secure traffic segmentation and prioritization of real-time applications. The industrial-grade software also supports broadcast storm control, port mirroring, and advanced monitoring tools to help manage network performance and troubleshoot issues quickly. The unit includes dual DC power inputs with alarm relays for redundancy and real-time power fault alerts, enhancing operational reliability. Additionally, the switch uses solid-state components with no moving parts, ensuring silent, maintenance-free operation in high-vibration environments. It supports a wide range of industrial certifications, making it suitable for use in automation, energy, transportation, and smart city applications.
Product Key Features
-
Compact 6-port managed Layer 2 switch designed for industrial environments
-
4× 10/100/1000 Mbps RJ-45 PoE+ ports (up to 30W per port, 120W total)
-
2× 1Gbps SFP slots for fiber or copper uplinks
-
Supports VLAN, STP, QoS, DHCP snooping, port mirroring, and IGMP snooping
-
Wide operating temperature range: –40°C to +75°C
-
Dual 12–54V DC power inputs with fault alarm relay I/O
-
Fanless DIN-rail mountable design with IP30-rated rugged metal housing
-
Intuitive GUI interface with support for CLI and SNMP for flexible management
-
Ideal for powering and managing networked devices in harsh industrial settings
Reliability & Performance :
The Cisco IE-1000-4P2S-LM-N delivers reliable and consistent performance under extreme conditions. Its industrial-grade hardware supports 5.6 Gbps switching capacity and 2.8 Gbps forwarding performance, ensuring minimal latency and high data throughput even under heavy loads. The fanless design removes the risk of mechanical failure and allows for silent operation in environments with high levels of dust or vibration.
Its dual DC input design ensures the switch continues to function even if one power source fails, while the integrated alarm relay provides real-time fault alerts to help operators respond swiftly. With a high MTBF (mean time between failures) and durable enclosure, it’s ideal for mission-critical deployments. Support for industry protocols such as 802.1Q VLANs, STP/MSTP, port-based ACLs, and QoS makes the switch a flexible and secure networking solution.
The switch’s hardened design is further enhanced with surge protection, EMC compliance, and immunity to shock and vibration, ensuring continued operation in rail systems, production lines, and outdoor cabinets. It provides industrial automation engineers and system integrators with a reliable foundation for secure, high-speed network infrastructure.
Key Features :
-
4× Gigabit PoE+ ports with up to 120W total power budget
-
2× 1Gbps SFP uplink ports for flexible fiber connectivity
-
Supports VLAN, STP, MSTP, IGMP snooping, ACLs, DHCP snooping
-
GUI, CLI, and SNMPv3 management interface options
-
Fanless, silent, solid-state design for high reliability
-
Dual 12–54V DC power inputs with alarm relay I/O
-
Wide temperature range: –40°C to +75°C
-
DIN-rail mountable with compact, rugged IP30-rated enclosure
-
128MB DRAM, 160MB flash memory for IOS and configuration
-
Designed for transportation, utilities, manufacturing, and automation
Specifications:
| Specification | Details |
|---|---|
| Model Number | Cisco IE-1000-4P2S-LM-N |
| Series | Cisco Industrial Ethernet 1000 Series |
| Product Type | Layer 2 Managed Industrial Ethernet Switch |
| Copper Ports | 4 × 10/100/1000Base-T PoE+ (RJ-45) |
| Uplink Ports | 2 × 1GbE SFP (fiber or copper transceivers supported) |
| PoE Capability | IEEE 802.3af/at, 30W per port, 120W total PoE budget |
| Memory | 128MB DRAM, 160MB Flash |
| Switching Capacity | 5.6 Gbps |
| Forwarding Rate | 2.8 Gbps |
| VLAN Support | IEEE 802.1Q, up to 256 active VLANs |
| Redundancy | Dual DC inputs (12V–54V), alarm relay output |
| Operating Temperature | –40°C to +75°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| Management Interfaces | Web GUI, CLI, SNMPv1/v2c/v3, RMON, Syslog, SSH |
| Security Features | Port security, ACLs, DHCP snooping, 802.1X authentication |
| Dimensions (H × W × D) | 5.0 × 1.8 × 5.3 in. (127 × 45.7 × 134 mm) |
| Enclosure Rating | IP30, fanless rugged metal housing |
| Mounting Type | DIN-rail (top hat profile) |
| Certifications | UL, CE, FCC, IEC 61000, EN 61000, EN 55032, EN 55024 |
| Weight | Approx. 1.7 lb (0.77 kg) |
| Warranty | Manufacturer’s Warranty (typically 5 years) |
Additional information
| Weight | 1.7 kg |
|---|---|
| Dimensions | 13.4 × 12.7 × 4.57 cm |
| Brand | Cisco |
