Cisco IE‑3300‑8P2S‑E‑N Catalyst IE3300 Rugged Series – Industrial Managed Switch with 8×1 GbE PoE/PoE+ & 2×1 GbE SFP Uplinks
Roll over image to zoom in
14,536.20 AED14,593.95 AED (-0%)
Cisco
IE‑3300‑8P2S‑E‑N Catalyst IE3300 Rugged Series – Industrial Managed Switch with 8×1 GbE PoE/PoE+ & 2×1 GbE SFP Uplinks
The Cisco IE‑3300‑8P2S‑E‑N is a high-performance, modular industrial switch designed for environments demanding rugged reliability and network flexibility. Equipped with 8 Gigabit Ethernet PoE/PoE+ ports and 2 Gigabit fiber uplinks, this 10-port managed switch is perfect for industrial automation, smart-city infrastructure, transportation systems, and manufacturing facilities. Housed in a fanless, DIN-rail-mountable chassis and rated for −40 °C to +75 °C operation, it delivers enterprise-grade connectivity where standard IT switches cannot survive. Powered by Cisco IOS XE and the Network Essentials license, it provides robust Layer 2 and basic Layer 3 functionality with integrated security, telemetry, and PoE for powering adjacent field devices.
Features :
The Catalyst IE3300 platform takes industrial networking to the next level by combining rugged hardware with carrier-class functionality. Built for harsh conditions, the IE‑3300 operates reliably in temperature extremes, resistance to shock, vibration, and electrical interference—all while offering versatile port configurations. The base unit includes eight copper ports capable of up to IEEE 802.3bt PoE+, delivering power to IP cameras, access points, sensors, and controllers at the network edge. The modular design supports one expansion module for adding copper, PoE, fiber, or even 10 GbE capabilities, scaling to up to 26 ports as needs grow. Uplink flexibility is ensured through two fixed Gigabit SFP slots, enabling resilient ring or star network topologies. The unit supports up to 360 W PoE budget—enough to power multiple devices—while maintaining compact efficiency
Advanced Options :
Cisco’s approach to manufacturing implementing IOS XE with secure boot, signed images, and Trust Anchor technology ensures system integrity. Network visibility is enhanced through Flexible NetFlow traffic analytics and compatibility with Cisco Secure Network Analytics and Cyber Vision for OT-level insight. Multi-protocol support (including Layer 3 routing), zero‑touch provisioning, and GUI-based Web UI simplify deployment and management.
Product Key Features
-
8 × 1 GbE copper ports with PoE/PoE+ (base supported up to 360 W)
-
2 × fixed 1 GbE SFP uplink ports (fiber-capable)
-
Modular support for expansion modules (up to 26 total ports)
-
Rugged design: fanless, DIN-rail, rated −40 °C to +75 °C
-
Enterprise security: MACsec 256-bit, secure boot, Trust Anchor
-
Full IOS XE: Layer 2 + basic Layer 3 routing, Flexible NetFlow
-
Supports Cisco IE-specific OT apps (Cyber Vision, Secure Equipment Access)
-
Management: GUI WebUI, SNMP, CLI, Catalyst Center, DNA Center
Reliability & Performance :
Designed for industrial-grade dependability, the IE‑3300 delivers wire-speed forwarding on all ports in extreme environments. With no fans and a convection-cooled chassis, it avoids failure-prone components while offering full Gigabit PoE support—ideal for powering IP devices without separate power injectors. The switch’s dual DC power inputs (9.6–60 V) provide redundancy and support mounting in remote cabinets, with alarm I/O for real-time system monitoring Network stability is reinforced through support for VLANs, STP/MSTP, QoS, ACLs, and IGMP snooping, while Layer 3 routing enables flexible OT-to-IT network integration. MACsec uplink encryption and secure boot ensure data safety even in untrusted field locations. Support for FlexNetFlow and IoX applications enables local analytics and decision-making at the edge. The modular build ensures enough port density while allowing future-proof capacity increases via encrypted expansion modules—a cost-effective path to scaling connectivity
Key Features :
-
8 × 10/100/1000Base-T PoE/PoE+ copper ports
-
2 × 1 GbE SFP uplink slots
-
Supports modular expansion (up to 26 ports)
-
Rugged, fanless housing rated −40 °C to +75 °C
-
PoE budget up to 360 W base; higher with modules
-
Secure IOS XE: MACsec encryption, secure boot
-
Layer 2 + Layer 3 routing, VLAN, QoS, ACLs, IGMP snooping
-
Flexible NetFlow analytics, OT visibility, edge app hosting
-
Dual DC power with alarm I/O; DIN-rail mountable
-
Centralized management (WebUI, CLI, SNMP, Catalyst Center)
Specifications:
| Specification | Details |
|---|---|
| Model Number | IE‑3300‑8P2S‑E‑N |
| Product Type | Rugged Industrial Managed Ethernet Switch |
| Copper Ports | 8 × 10/100/1000Base-T PoE/PoE+ |
| Uplink Ports | 2 × 1 GbE SFP (fiber/copper) |
| PoE Budget | Base up to 360 W; expandable |
| Switching Capacity | 20 Gbps (wire-speed) |
| Forwarding Rate | Full line-rate for all ports |
| Expansion Modules | Support up to 26 ports total |
| Operating Temp | −40 °C to +75 °C |
| Power Input | Dual 9.6–60 VDC, alarm I/O |
| Housing & Mounting | Metal enclosure, fanless, DIN-rail mounting |
| Environmental Ratings | Shock, vibration, EMC industrial grades |
| Software | Cisco IOS XE with Network Essentials License |
| Security | MACsec 256-bit, secure boot, Trust Anchor, ACLs |
| Analytics | Flexible NetFlow, Cyber Vision, Secure Equipment Access |
| Management Tools | WebUI, CLI, SNMP, Catalyst Center, DNA Center |
| Certifications | IEC, IEEE 1613, EN 61850-3, etc. |
| Dimensions (H×W×D) | ~152 × 91 × 135 mm (6 × 3.6 × 5.3 in) |
| Weight | ~1.7 kg (3.8 lb) |
| Warranty | 5‑Year Hardware with Lifetime Replacement |
Additional information
| Weight | 1.7 kg |
|---|---|
| Dimensions | 13.5 × 9.1 × 15.2 cm |
| Brand | Cisco |
