Cisco Catalyst IE‑3105‑18T2C‑E Rugged Managed Switch Network Essentials – 20 Ports
10,078.95 AED10,288.95 AED (-2%)
Cisco Catalyst
IE‑3105‑18T2C‑E
Rugged Managed Switch Network Essentials 20 Ports
The Cisco Catalyst IE‑3105‑18T2C‑E is a heavy-duty, fixed-port industrial switch designed for rugged environments, delivering enterprise-grade Layer 2 switching capabilities via Cisco’s Network Essentials software. Boasting 18 Gigabit RJ‑45 copper ports and 2 combo ports (each supporting RJ‑45 or SFP), this switch enables flexible connectivity and reliable performance. Housed in a fanless, DIN-rail or wall-mount chassis and rated for –40 °C to +75 °C, the IE‑3105 is ideal for automation, transportation, utilities, and outdoor deployments requiring robust connectivity in extreme conditions.
Features :
The Cisco IE‑3105‑18T2C‑E rugged switch provides high-availability networking through its full catalog of Layer 2 features, including VLANs, QoS with hardware queuing, link aggregation, IGMP snooping, and STP variants. Powered by Cisco’s Network Essentials software,
Advanced Options :
it adds secure management and segmentation without the complexity of Layer 3 routing. Dual 12–58 VDC power inputs with relay alarm outputs support redundant power, while USB/SD‑card backup ensures configuration resilience. Compact yet durable, its fanless design resists dust and moisture, making it perfect for field and industrial edge applications.
Product Key Features
-
18 × 1 Gbps RJ‑45 ports + 2 × combo RJ‑45/SFP uplinks
-
Rugged operating range: –40 °C to +75 °C in fanless enclosure
-
Cisco Network Essentials software: VLAN, QoS, LACP, STP, IGMP
-
Dual power inputs (12–58 VDC) with alarm relay support
-
Security via SSHv2, SNMPv3, 802.1X, ACLs
-
Zero-touch provisioning via DHCP, USB/SD backup support
Reliability & Performance :
With a switching capacity of 38 Gbps and forwarding performance around 28 Mpps, the IE‑3105 delivers reliable throughput for dense deployments. The fanless metal shell withstands shock, vibration, and temperature extremes, certified to IEC 61373, and is suitable for transportation and industrial use. Cisco’s rugged design coupled with uptime-focused hardware ensures high MTBF and minimal downtime, while integrated diagnostics and configuration backup enable quick recovery in critical environments.
Key Features :
-
20 fixed ports: 18×Gigabit copper, 2×RJ‑45/SFP combo
-
–40 °C to +75 °C rated, metal, fanless enclosure
-
Network Essentials: VLAN, QoS, link aggregation, STP, IGMP snooping
-
Secure management: SSHv2, SNMPv3, 802.1X, ACL facilities
-
Dual wide-range 12–58 VDC power inputs with relay
-
USB/SD backup and zero-touch deployment
-
Industrial-grade shock/vibration (IEC 61373)
Specifications:
Specification | Details |
---|---|
Model Number | IE‑3105‑18T2C‑E |
Product Type | Industrial Layer 2 Managed Switch |
Copper Ports | 18 × 10/100/1000 Mbps RJ‑45 |
Combo Uplink Ports | 2 × Gigabit RJ‑45/SFP |
Switching Capacity | 38 Gbps |
Forwarding Rate | ~28 Mpps |
VLAN Support | 4K VLANs |
QoS Queues | 8 hardware queues |
MAC Address Table | 8K addresses |
Power Inputs | 2 × 12–58 VDC + relay alarms |
Power Consumption | ~8–15 W |
Operating Temp | –40 °C to +75 °C |
Enclosure Rating | Fanless metal, industrial grade |
Shock/Vibration Rating | IEC 61373 |
Configuration Backup | USB/SD |
Management Interfaces | CLI, Web GUI, SNMP |
Security Features | SSHv2, SNMPv3, 802.1X, ACLs |
Mounting Options | DIN‑rail or wall-mount |

Additional information
Weight | 1.27 kg |
---|---|
Dimensions | 12.9 × 10.92 × 12.7 cm |
Brand | Cisco |
