Cisco Catalyst C9300X-48HX-A 9300X Series 48-Port Multigigabit Managed Switch

In stock

Please fill the form to get price quote.

Please enable JavaScript in your browser to complete this form.
SKU: C9300X-48HX-A Category: Tag: Brand:

Cisco Catalyst

C9300X-48HX-A

9300X Series 48-Port Multigigabit Managed Switch



The Cisco Catalyst C9300X-48HX-A is a high-performance, enterprise-grade switch engineered for next-gen campus and edge deployments. Designed with 48 Multigigabit (mGig) ports and integrated Network Advantage software, it delivers exceptional throughput, security, and scalability for digital-ready infrastructures. Ideal for organizations requiring bandwidth-intensive applications like Wi-Fi 6/6E, unified communications, and advanced security, this rack-mountable switch supports a wide array of use cases from modern workspaces to high-speed aggregation. The C9300X-48HX-A provides unmatched flexibility and intelligence, ensuring long-term investment protection in enterprise networks.

Features :

The Cisco Catalyst C9300X-48HX-A extends the powerful Catalyst 9000 series with robust Multigigabit support across all 48 ports, accommodating speeds from 100Mbps to 10Gbps per port. This makes it ideal for next-generation wireless access points and evolving endpoint demands. Combined with 100G uplink capabilities (with optional network modules), this switch is purpose-built to handle rising network traffic and user demands with efficiency and resilience.

Advanced Options :

With the Network Advantage license, the switch supports advanced Layer 3 routing protocols (BGP, OSPF, EIGRP), Cisco SD-Access, TrustSec, and macro/micro-segmentation. Cisco StackWise-1T provides up to 1Tbps stacking bandwidth, while hot-swappable redundant components ensure high availability. Featuring full programmability through Cisco IOS XE and support for model-driven telemetry, the C9300X-48HX-A offers centralized visibility, automation, and security — perfect for enterprise campus cores and large-scale branch networks.

Product Key Features

  • 48 x Multigigabit (mGig) ports supporting up to 10Gbps

  • Integrated Network Advantage software for full Layer 3 feature set

  • StackWise-1T support for 1 Tbps stack bandwidth

  • Advanced security: MACsec-256 encryption, TrustSec, and Secure Boot

  • Cisco DNA Center and SD-Access ready

  • Programmability via Cisco IOS XE with model-driven telemetry


Reliability & Performance :

Engineered for long-term reliability and top-tier performance, the Cisco C9300X-48HX-A is built with advanced hardware and software capabilities to support modern IT demands. Each port dynamically adjusts between 100Mbps to 10Gbps, ensuring consistent performance even in bandwidth-heavy environments. The modular architecture enables hot-swappable redundant power supplies and fan trays, minimizing downtime and allowing seamless maintenance in live networks.

StackWise-1T allows up to 8 switches to operate as a single unit, improving fault tolerance and operational simplicity. The device’s advanced feature set ensures maximum protection with MACsec-256 encryption and secure software boot. Whether deployed in high-density campus cores or distributed enterprise environments, the C9300X-48HX-A consistently delivers superior uptime, flexibility, and protection for evolving infrastructure needs.

Key Features :

  • 48 x Multigigabit (100Mbps/1G/2.5G/5G/10G) ports

  • Network Advantage software license included

  • Full Layer 3 routing support (OSPF, EIGRP, BGP)

  • StackWise-1T: 1 Tbps stacking bandwidth

  • MACsec-256 encryption & TrustSec security

  • Redundant hot-swappable power supplies & fans

  • Model-driven telemetry & open APIs

  • Supports Cisco DNA Center & SD-Access

Specifications:

Specification Details
Model Number C9300X-48HX-A
Product Type Managed Layer 3 Switch
Total Ports 48 x Multigigabit Ethernet
Port Speeds 100M/1G/2.5G/5G/10G
Software License Network Advantage
Switching Capacity Up to 1.6 Tbps
Forwarding Rate Up to 1.19 Bpps
StackWise Support StackWise-1T (1 Tbps)
Operating System Cisco IOS XE
Power Supply Redundant, hot-swappable (sold separately)
Form Factor Rack-Mountable – 1U
Dimensions (H x W x D) 1.73 x 17.5 x 17.5 in (4.4 x 44.5 x 44.5 cm)
Weight Approx. 17.2 lbs (7.8 kg)

Additional information

Weight 6.62 kg
Dimensions 1.73 × 17.5 × 22.03 cm
