Cisco Catalyst C9200L‑24P‑4X‑E‑N 9200L Series 24‑Port PoE+ Managed Ethernet Switch with 4 × 10G Uplinks
6,445.95 AED6,823.95 AED (-6%)
Cisco Catalyst
C9200L‑24P‑4X‑E‑N 9200L Series 24‑Port PoE+ Managed Ethernet Switch with 4 × 10G Uplinks
The Cisco Catalyst C9200L‑24P‑4X‑E‑N is a full-featured, rack-mountable Layer 3 switch tailored for enterprise and branch-office deployments that demand high performance, security, and scalability. Featuring 24 auto-sensing Gigabit PoE+ ports and four fixed 10G SFP+ uplink interfaces, this switch delivers a robust 370 W PoE+ budget ideal for powering IP phones, wireless access points, security cameras, and more. Operating on Cisco’s trusted IOS XE platform with the Network Essentials license, it offers advanced switching, basic routing, and enterprise-grade features—all packed in a 1U form factor. Engineered to bring Cisco DNA programmability and energy efficiency to mid-sized IT environments, the C9200L simplifies network expansion while delivering reliability and future-proofing for evolving demands.
Features :
Part of the Cisco Catalyst 9200L family, the C9200L‑24P‑4X‑E‑N stands out with its balanced feature set—combining PoE+ power, 10G uplinks, and essential Layer 3 capabilities within an easily managed rack-mountable chassis. The switch includes 24 IEEE 802.3at PoE+ ports and four 10G SFP+ uplinks, all with wire-speed data handling for efficient campus or branch network backhaul. With a 128 Gbps switching capacity and a 190.4 Mpps forwarding rate, it supports converged services such as voice, video, and wireless without bottlenecks.
Advanced Options :
Thanks to dual fixed internal fans (non-field replaceable), redundant power options, and ENERGY STAR certification, it balances performance with energy efficiency. The switch supports management via the Cisco Business Dashboard, CLI, SNMP, and REST APIs, with optional Bluetooth console access—streamlining deployment and troubleshooting.
Product Key Features
-
24 × 10/100/1000 Mbps PoE+ ports (370 W total budget)
-
4 × 10 G SFP+ fixed uplinks
-
Layer 2 plus basic Layer 3 routing (static, RIP, OSPF, IPv6)
-
Cisco IOS XE with Network Essentials license
-
Dual fixed fans and redundant power design
-
128 Gbps switching capacity; 190.4 Mpps forwarding
-
Stacking support up to 80 Gbps
-
ENERGY STAR certified for energy-efficient operation
-
Management via Dashboard, CLI, SNMP, REST, Bluetooth console
-
Secure architecture with Trust Anchor, secure boot, MACsec-ready
Reliability & Performance :
Built for high availability and operational resilience, the Catalyst C9200L‑24P‑4X‑E‑N incorporates dual fixed fans, redundant internal PSU options, and stacking with sub‑50 ms failover. The ENERGY STAR rating and support for IEEE 802.3az energy-efficient Ethernet save power without compromising performance. With a UADP ASIC, IOS XE, and cold-patching, the switch delivers modern programmability with seamless updates and integrated security. It handles converged traffic—voice, wireless, security, video—while maintaining efficient PoE+ power distribution. DNS segmentation, MACsec readiness, and secure management interfaces offer peace of mind in various enterprise and mid-sized deployments.
Key Features :
-
24 1 Gb PoE+ ports (370 W)
-
4 10 G SFP+ fixed uplinks
-
Layer 2 & basic Layer 3 routing: RIP, OSPF, static, IPv6
-
Dual fixed fans, redundant power supply support
-
Cisco IOS XE with Network Essentials
-
Stacking capability (80 Gbps backplane)
-
ENERGY STAR certified, EEE support
-
Management: Dashboard, CLI, SNMP, REST, Bluetooth console
-
Psychic security: Trust Anchor, secure boot, MACsec-ready
-
Cold-patching for agile update deployment
Specifications:
| Specification | Details |
|---|---|
| Model Number | C9200L‑24P‑4X‑E‑N |
| Product Type | Managed PoE+ Ethernet Switch |
| Downlink Ports | 24 × 10/100/1000 RJ‑45 PoE+ |
| Uplink Ports | 4 × 10 G SFP+ |
| PoE Budget | 370 W (single PSU), expandable (Cables And Kits) |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 190.4 Mpps |
| MAC Table | 16,000 addresses |
| Stacking Bandwidth | 80 Gbps |
| Fans | Dual fixed, redundant |
| Power Supply | PWR‑C5‑600WAC (default); optional redundant |
| Operating System | Cisco IOS XE (Network Essentials) |
| Energy Efficiency | ENERGY STAR, IEEE 802.3az EEE |
| Ports Protection | Secure Boot, Trust Anchor, MACsec-ready |
| Physical Dimensions | 1.73″×17.5″×11.3″ (H×W×D) ≃ 44.5×28.8×4.4 cm |
| Weight | ≈10.4 lb (4.7 kg) |
| Operating Temp | 0 °C to 40 °C |
| Management Interfaces | CLI, Dashboard, SNMP, REST, Bluetooth console |
Additional information
| Weight | 4.71 kg |
|---|---|
| Dimensions | 28.8 × 44.5 × 4.4 cm |
| Brand | Cisco |
