Cisco Catalyst C1000‑16T‑E‑2G‑L‑N 16‑Port Gigabit Ethernet Managed Switch with 2× 1 Gb SFP Uplinks
912.45 AED943.95 AED (-3%)
Cisco Catalyst
C1000‑16T‑E‑2G‑L‑N – 16‑Port Gigabit Ethernet Managed Switch with 2× 1 Gb SFP Uplinks
The Cisco Catalyst C1000‑16T‑E‑2G‑L‑N is an enterprise‑class Layer 2 managed switch offering roll‑out simplicity and reliable performance for small offices, branch locations, and IoT environments. With 16 Gigabit Ethernet ports and two SFP uplinks, it supports robust connectivity for desktop devices, phones, security cameras, and more. Equipped with Cisco IOS® Software, the switch provides familiar CLI and web UI management, along with advanced capabilities like VLAN segmentation, QoS, ACLs, and 802.1X authentication—all in a compact, rack‑mountable, fan‑less chassis.
Features :
The Catalyst C1000 series is designed to simplify deployments while delivering the essential features of enterprise‑grade networking. The 16T‑E‑2G‑L‑N variant includes an external power supply, ideal for environments where internal power might increase heat or maintenance complexity. Fan‑less design, with a depth under 8.3 inches, makes it quiet and unobtrusive—perfect for offices, classrooms, or retail setups.
Advanced Options :
Powered by Cisco IOS, it supports Layer 2 switching with a 36 Gbps switching bandwidth, 18 Gbps forwarding capacity, and 26.78 Mpps performance—ensuring seamless data flow even under load. Security features such as ACLs, 802.1X, IP Source Guard, and BPDU Guard protect against unauthorized access, while SNMP, sFlow, and SPAN simplify monitoring and troubleshooting. For time-sensitive environments, PoE options are available on other models, though this data‑only version retains flexibility and power efficiency.
Product Key Features
-
16 × Gigabit (10/100/1000) RJ‑45 data ports
-
2 × fixed 1 Gb SFP uplink ports
-
36 Gbps switching capacity, 18 Gbps forwarding rate
-
Fan‑less, compact 1 RU design (chassis depth ~8.26″)
-
Secure management via CLi, web UI, SNMP, sFlow
-
Cisco IOS layer‑2 features: VLAN, QoS, ACL, spanning tree
-
Strong access control: 802.1X, port security, IP Source Guard
-
External power supply for reduced heat and service flexibility
-
Energy‑efficient per IEEE 802.3az (EEE standards)
Reliability & Performance :
The Catalyst C1000‑16T‑E‑2G‑L‑N is built for consistent, long‑term reliability. With a high MTBF and Cisco’s enhanced limited lifetime warranty, including advance replacement, this switch supports continuous network availability. Its passive cooling design eliminates mechanical failures and reduces noise—ideal in environments sensitive to distractions. Environmental resilience spans from –5 °C to +50 °C and up to 90 % non‑condensing humidity. With standard dimensions (10.56″ W × 8.26″ D × 1.73″ H) and a weight of ~1.42 kg (3.13 lb), it fits neatly into standard 19″ racks or desktop setups. The external power brick facilitates easier PSU replacement and ensures that the internal switch remains compact and cool, even in environments with limited ventilation.
Key Features :
-
16 × 10/100/1000 Mbps RJ‑45 ports
-
2 × 1 Gb SFP uplinks
-
36 Gbps non‑blocking switch fabric
-
Cisco IOS with Layer 2 features (VLAN, QoS, ACLs, STP)
-
Management via CLI, Web UI, SNMP, sFlow, SPAN
-
Access security: 802.1X, port security, IP Source Guard
-
Fan‑less, silent 1 RU chassis
-
External power supply included
-
Energy Efficient Ethernet compliant
Specifications:
| Specification | Details |
|---|---|
| Model Number | C1000‑16T‑E‑2G‑L‑N |
| Product Type | Layer 2 Managed Gigabit Ethernet Switch |
| Access Ports | 16 × 10/100/1000 Mbps RJ‑45 |
| Uplink Ports | 2 × 1 Gbps SFP fixed |
| Switching Capacity | 36 Gbps non‑blocking |
| Forwarding Rate | 18 Gbps (~26.78 Mpps at 64‑byte packets) |
| Memory / Storage | 512 MB DRAM; 256 MB flash |
| Management Interfaces | CLI (console/SSH), Embedded Web UI, SNMP v1/2/3, sFlow, SPAN |
| Layer 2 Features | VLANs, QoS, ACLs, STP/RSTP, Link Aggregation, IGMP snooping |
| Security | 802.1X, Port Security, IP Source Guard, BPDU Guard |
| Cooling | Fan-less passive cooling |
| Dimensions (WxDxH) | 10.56″ × 8.26″ × 1.73″ (~268 × 210 × 44 mm) |
| Weight | ~3.13 lbs (1.42 kg) |
| Power Supply | External AC adapter (100–240 V AC) |
| Power Consumption (max) | ~36.7 W (no PoE) |
| Operating Temperature | –5 °C to +50 °C; 5–90 % RH |
| Warranty | Enhanced Limited Lifetime (next‑business‑day replacement) |
Additional information
| Weight | 1.42 kg |
|---|---|
| Dimensions | 21.08 × 26.92 × 4.32 cm |
| Brand | Cisco |
